Dlubal RX-TIMBER 2.29.01 (x64) Multilingual
File Size: 793.8 MB

RX‑TIMBER Continuous Beam analyzes beams according to EN 1995‑1‑1 (Eurocode 5) or DIN 1052:2008‑12. The program performs the ultimate and the serviceability limit state designs as well as fire resistance designs.

Features
Design of the following geometrical models
Single-span beams with and without cantilevers
Continuous beams with and without cantilevers
Hinged girder system (Gerber beams) with and without cantilevers
For design according to EC 5 (EN 1995), the following National Annexes are currently available
United Kingdom BS EN 1995-1-1/NA:2009-10 (United Kingdom)
ÖNORM B 1995-1-1:2015-06 (Austria)
Belgium NBN EN 1995-1-1/ANB:2012-07 (Belgium)
CSN EN 1995-1-1:2009-07 (Czech Republic)
DK EN 1995-1-1/NA:2011-12 (Denmark)
SFS EN 1995-1-1/NA:2007-11 (Finland)
NF EN 1995-1-1/NA:2010-05 (France)
DIN EN 1995-1-1/NA:2013-08 (Germany)
UNI EN 1995-1-1/NA:2010-09 (Italy)
NEN EN 1995-1-1/NB:2007-11 (Netherlands)
PN EN 1995-1-1/NA:2010-09 (Poland)
STN EN 1995-1-1/NA:2008-12 (Slovakia)
SIST EN 1995-1-1/A101:2006-03 (Slovenia)
SS EN 1995-1-1 (Sweden)
Automatic generation of wind and snow loads
Multiple optional reductions according to the selected standard
Simple geometry input with illustrative graphics
Free entry of tapered geometries; free selection of the grain angle allows for a user-defined design of the compressive and tensile areas for bending
Comprehensive and extandable material library
Determination of design criteria, support forces and deformations
Color reference scales in result tables
Direct data export to MS Excel
DXF interface for preparation production documents in CAD
Program languages: English, German, Czech, Italian, Spanish, French, Portuguese, and Russian
Verifiable printout report with all required designs available in many languages, for example English, German, French, Italian, Spanish, Russian, Czech, Polish, Portuguese, Dutch
Direct import of stp files from various CAD programs
