PROTO - circuit simulator v1.15.0

Requirements: Android 5.0+ | File size: 23,02 MB

Are you looking for tools like Multisim, SPICE, LTspice, Proteus or Altium? That's great! PROTO is an real time electronic circuit simulator which means you are able to setup a circuit with various components and simulate behaviour of the electronic circuit. During simulation you can check voltages, currents and many other variables. Check signals on multichannel oscilioscope and tune your circuit in real time! You can also use PROTO as logic circuit simulator and perform digital electronic analysis!

Features
• Animations of voltage values and current flows
• Adjusts circuit parameters (like voltage, current and other)
• Four-channel oscilloscope
• Single play/pause button to control simulation
• Copy electronic components
• Learn about electronic circuits by examples in app
• Share circuit with friends

Components
• DC, AC, Square, Trinagle, Sawtooth, Pulse, Noise voltage source
• Current source
• Resistor
• Potentiometer
• Capacitor
• Polarized capacitor
• Inductor
• Transformer
• Diode (rectifying diode, LED, Zener, Schottky)
• Transistor (NPN, PNP, N and P channel Mosfet)
• Switches (SPST, Relay)
• Bulb
• Operational amplifier
• Timer 555 (NE555)
• Digital Gates (AND, NAND, OR, XOR, NOR, NXOR, Inverter)
• Voltmeter
• Ammeter
• Fuse
• Photoresistor (uses phone light sensor)
• Analog-to-digital converter (ADC)
• Accelerometer (uses phone accelerometer sensor)
• FM source
• Logic Input
• Memristor
• Logic output

Analog Pack
• Tunnel diode
• Varactor
• NTC Thermistor
• Center tapped transformer
• Schmitt trigger
• Schmitt trigger (inverting)
• Solar cell
• TRIAC
• DIAC

Digital Pack
• Adder
• Counter
• Latch
• PISO Register
• SIPO Register
• Seven segment decoder
• Sequence generator
• D Flip-flop
• T Flip-flop
• JK Flip-flop
• Multiplexer
• Demultiplexer

Misc Pack
• Wobbulator
• AM Source
• SPDT Switch
• Digital to analog converter (DAC)
• Antenna
• Spark gap
• LED Bar
• RGB LED
• Ohmmeter
• Audio input
• Microphone
• Device battery

Sensors pack
• Pressure
• Gyroscope
• Light
• Magnetic field
• Proximity
• Temperature
